Enterprise Integration Patterns
Messaging Patterns
Event-Driven ConsumerEvent-Driven ConsumerMessaging Patterns » Messaging Endpoints

An application needs to consume Messages as soon as they’re delivered.

How can an application automatically consume messages as they become available?

The application should use an Event-Driven Consumer, one that is automatically handed messages as they’re delivered on the channel.

This is also known as an asynchronous receiver, because the receiver does not have a running thread until a callback thread delivers a message. We call it an Event-Driven Consumer because the receiver acts like the message delivery is an event that triggers the receiver into action.


Example: RabbitMQ ConsumerNEW

RabbitMQ consumers are by default event-driven. When consuming messages off a Channel, you have to provide an implementation of the Consumer interface. The following code example sets up a very simple consumer that simply prints incoming messages as strings:

Consumer consumer = new DefaultConsumer(channel) {
  public void handleDelivery(
        String consumerTag,
        Envelope envelope,
        AMQP.BasicProperties properties,
        byte[] body) throws IOException {
    String message = new String(body, "UTF-8");
    System.out.println("Received '" + message + "'");

boolean autoAck = true;
channel.basicConsume(queueName, autoAck, consumer);

This implementation is not a Transactional Client because the client acknowledges messages automatically on receipt but before processing.

The complete source code for this example can be found on Github.

Related patterns: Competing Consumers, Durable Subscriber, Message, Message Channel, Message Dispatcher, Selective Consumer, Polling Consumer, Transactional Client
